Receiver:

Model No.: X1mots-DC

Channel: 1 CH

Control Modes: Toggle, Momentary.

Coding Type: learning code

Coding Setting: By learning

Power Supply (Operating Voltage):DC6V-50V,

Maximum Working Current: 10A

Transmitter:

Model No.: R-2

Channel: 2 CH

Remote Control Distance: 100m / 300ft (theoretically)

Encode: learning code

Power Supply:  cr2016 3v  battery (included, can be used for 12 months)

Usage:

Setting different control modes (We have set the receiver as Toggle control mode before delivery. If you want to use other control modes, do as

following operation):

1.Setting control mode Toggle: Only connect 1.

Toggle mode: Press button A,Motor forward, Press button A again,Motor stop.

2.Setting control mode Momentary: Only connect 2.

Control mode Momentary: Press and hold -> On; Release -> Off.

Press and hold button A: Motor forward.,Release button A,Motor stop
